Inspection square 90° (rectangular, slender)
- Hard and wear-resistant.
- Surface accuracy according to DIN 876.
- Angularity according to DIN 875.
Provided with relief holes to reduce weight and improve handling.
The 4 narrow outer sides are machined at right angles and parallel to each other.
We also offer a suitable bag for precision measuring equipment.
400 mm
Cross-section: 160x110 mm
Permissible deviation for squareness: 0.003 mm
Weight: 18 kg
Item no. 4-sided accuracy: 215-901
585 mm
Cross-section: 180x130 mm
Permissible deviation for squareness: 0.003 mm
Weight: 36 kg
Item no. 4-sided accuracy: 215-902
845 mm
Cross-section: 225x150 mm
Permissible deviation for squareness: 0.004 mm
Weight: 70 kg
Item no. 4-sided accuracy: 215-903
1100 mm
Cross-section: 300x180 mm
Permissible deviation for squareness: 0.005 mm
Weight: 140 kg
Item no. 4-sided accuracy: 215-904
1300 mm
Cross-section: 350x210 mm
Permissible deviation for squareness: 0.005 mm
Weight: 250 kg
Item no. 4-sided accuracy: 215-905
1650 mm
Cross-section: 400x250 mm
Permissible deviation for squareness: 0.006 mm
Weight: 450 kg
Item no. 4-sided accuracy: 215-906
